Study: Seawalls, coastal forests in Japan help reduce tsunami damage
The analysis was performed by researchers at Tohoku University, Maryland Institute College of Art, the University of Michigan and Purdue University. The researchers studied data from tsunamis in 1896, 1933, 1960, and 2011.
“These events have caused large loss of life and damage throughout the coastal region, and there has been uncertainty about the degree to which seawalls reduce deaths and building damage,” said Jeremy D. Bricker, an associate professor in the International Research Institute of Disaster Science at Tohoku University in Japan.
The Japanese have embarked on a 10-year reconstruction project costing about 31.5 trillion yen, or about $255 billion, which includes the construction of tsunami seawalls along Tohoku’s Pacific coast. Critics of the program have voiced skepticism about the effectiveness of seawalls.
However, new findings detailed in a research paper appearing on Aug. 10 in the journal PLOS ONE, may bolster support for seawalls and coastal forests. (A youtube video is available ab https:/
“Some have suggested that seawalls cause a sense of complacency in residents, leading to lower evacuation rates and the tendency to develop residences in hazardous low-lying areas,” said Seth Guikema, an associate professor in the Department of Industrial and Operations Engineering and the Department of Civil and Environmental Engineering at the University of Michigan. “However, our results cast serious doubt on this theory. The presence or size of seawalls and coastal forests does not strongly influence residents’ decisions on whether or not to evacuate.”
The new research findings demonstrate that both seawalls higher than 5 meters and coastal forests do, in fact, reduce damage and death from tsunamis. The paper’s lead author was Roshanak Nateghi, an assistant professor in Purdue’s School of Industrial Engineering and Division of Environmental and Ecological Engineering. She co-authored the paper with Bricker, Guikema and Maryland Institute College of Art student Akane Bessho.
The heights and construction methods of sea walls vary widely from one community to another, and even within the same town.
“In fact, there are many sub-municipalities that still don’t have seawalls,” Nateghi said. “We analyzed these four tsunamis and found that statistically, seawalls above 5 meters are related to a decrease in destruction rate.”
Nateghi used a modeling method called Random Forest, which harnesses numerous “decision trees” to capture complex non-linear relationships of data. Seawalls more than 5 meters high were shown to reduce the destruction rate, and, more specifically, a 10-meter increase in height was associated with about a 5-6 percent decrease in the destruction rate.
Findings also showed the protective value of coastal “tsunami control” forests.
“We saw that in the areas with a lot of coastal forest you have reduced damage and destruction, and the extent of flooding is a big predictor in our models,” Nateghi said.
Moreover, the presence of coastal forests was found to reduce death and destruction rates by displacing development that would otherwise have been damaged.
The findings showed the extent of flooding is a critical factor in death rates and building damage rates, suggesting that additional measures, such as multiple lines of defense and elevating topography, may have significant benefits in reducing the impacts of tsunamis.
The same analysis method also could be used to study tsunamis in other regions.
“All the insights are conditioned on the type of infrastructure you have in place, the topography and intensity of the tsunami,” Nateghi said. “But the methodology is extendable. You could do similar analyses for other regions using this method.”
Note to Journalists: A copy of the research paper is available at http://dx.
The research was funded by the National Science Foundation and the Japan Society for the Promotion of Science. (The paper is available at http://dx.
Writer: Emil Venere, 765-494-4709, firstname.lastname@example.org
Sources: Roshanak Nateghi, 765-494-7059, email@example.com
Seth Guikema, 734-764-6475, firstname.lastname@example.org
Jeremy D. Bricker, email@example.com
Learning from Historical Data: The Role of Seawalls and Coastal Forests in Reducing Tsunami Death and Damage Rates along the Coasts of Iwate and Miyagi Prefectures
Roshanak Nateghi1, Jeremy D. Bricker2, Seth Guikema3, Akane Bessho4
1 School of Industrial Engineering and Division of Environmental and Ecological Engineering, Purdue University, West Lafayette, IN, USA
2 International Research Institute of Disaster Science, Tohoku University, Sendai, Japan
3 Department of Industrial and Operations Engineering, University of Michigan, Ann Arbor, MI, USA
4Undergraduate Program in Architectural Design, Maryland Institute College of Art, Baltimore, MD, USA Corresponding author E-mail: firstname.lastname@example.org
The Pacific coast of the Tohoku region of Japan experiences repeated tsunamis, with the most recent events having occurred in 1896, 1933, 1960, and 2011. These events have caused large loss of life and damage throughout the coastal region. There is uncertainty about the degree to which seawalls reduce deaths and building damage during tsunamis in Japan. On the one hand they provide physical protection against tsunamis as long as they are not overtopped and do not fail. On the other hand, the presence of a seawall may induce a false sense of security, encouraging additional development behind the seawall and reducing evacuation rates during an event. We analyze municipality-level and sub-municipality-level data on the impacts of the 1896, 1933, 1960, and 2011 tsunamis, finding that seawalls larger than 5 m in height generally have served a protective role in these past events, reducing both death rates and the damage rates of residential buildings. However, seawalls smaller than 5 m in height appear to have encouraged development in vulnerable areas and exacerbated damage. We also find that the extent of flooding is a critical factor in estimating both death rates and building damage rates, suggesting that additional measures, such as multiple lines of defense and elevating topography, may have significant benefits in reducing the impacts of tsunamis. Moreover, the area of coastal forests was found to be inversely related to death and destruction rates which was expected since they displace development that would otherwise have been damaged.
